1. Unique design of exemption from boiler usage certificate
Water volume compliance: This series of products has a water volume of less than 50L, which meets the national standard of exemption from boiler usage certificate and simplifies the approval process before use.
Efficient steam water separation: The furnace has a built-in steam water separator, which significantly reduces the moisture content of steam and improves steam quality.
2. Fully automatic intelligent electronic control system
Computer soldering technology: The circuit board adopts fully automatic computer soldering, which is more stable and reliable compared to traditional manual soldering.
LCD display monitoring: Comprehensive visualization of operating status, including electric heating tubes, water level, steam pressure, water pumps, and fault alarms. It supports four time period timed control, making it easy for users to grasp the boiler status at any time.
3. Energy saving control mode
On demand start-up: The boiler can be grouped for control, and the heating group can be flexibly started according to steam demand to achieve system energy saving.
4. High quality component configuration
Electric heating tube: Made of thick walled 316L stainless steel material, it can withstand high temperatures up to 900 ℃, has a long service life, and is easy to replace and repair.
Electrical accessories: Choose well-known domestic brands to ensure safety and reliability.
Pipeline connection: The internal pipelines and instruments are connected by copper pipes, which are corrosion-resistant and rust proof, and enhance the durability of the equipment.
5. Multiple security protections
Overpressure protection: equipped with safety valves, pressure controllers, etc., to prevent boiler explosions.
Low water level protection: Automatically shut down the furnace when the water supply stops to prevent dry burning damage.
Leakage protection: ensuring the safety of operators and equipment.
6. Strict quality inspection
Factory inspection: The inner liner welds undergo X-ray inspection and hydrostatic testing to ensure safety and no hidden dangers.
7. Convenient installation and use
Plug and play: The product has been debugged before leaving the factory, and users only need to connect the power and water sources to start running.
8. Exquisite exterior design
Scientific layout: Cabinet style design, reasonable structure, easy to maintain and repair.
Appearance technology: The shell adopts CNC cutting and folding technology, high-temperature spray coating treatment, which is beautiful and durable.
9. Environmental protection and energy conservation
Electricity utilization: pollution-free, utilizing low valley electricity can significantly reduce operating costs, making it an ideal choice for energy conservation and environmental protection.
In summary, this product integrates efficiency, intelligence, energy conservation, safety, and aesthetics, making it a reliable and preferred boiler equipment for users.
| Product parameters |
|
||||||||
|
Series Product Model
|
WDL-DM 45-0.8
|
WDL-DM 50-0.8
|
WDL-DM 60-0.8
|
WDL-DM 72-0.8
|
WDL-DM 90-0.8
|
WDL-DM 100-0.8
|
WDL-DM 108-0.8
|
WDL-DM 120-0.8
|
WDL-DM 144-0.8
|
|
Boiler Product Model
|
LDR 0.07-1.0
|
LDR 0.07-1.0
|
LDR 0.103-1.0
|
LDR 0.103-1.0
|
LDR 0.17-0.8
|
LDR 0.17-0.8
|
LDR 0.17-0.8
|
LDR 0.17-0.8
|
LDR 0.2-0.8
|
|
Electric power(KW)
|
45
|
50
|
60
|
72
|
90
|
100
|
108
|
120
|
144
|
| Rated evaporation(Kg/h) | 64 | 70 | 86 | 103 | 129 | 143 | 150 | 170 | 200 |
| Source voltage(V) | 380 | 380 | 380 | 380 | 380 | 380 | 380 | 380 | 380 |
| Rated pressure(MPa) | 0.8 | 0.8 | 0.8 | 0.8 | 0.8 | 0.8 | 0.8 | 0.8 | 0.8 |
| Steam temperature(℃) | 175 | 175 | 175 | 175 | 175 | 175 | 175 | 175 | 175 |
| Power wire(mm²) | 16 | 25 | 35 | 50 | 50 | 70 | 70 | 95 | 150 |
| Dimension(mm)L*W*H | 1030x550x1340 | 1030x550x1340 | 1030x550x1340 | 1030x550x1340 | 1210x600x1440 | 1210x600x1440 | 1210x600x1440 | 1210x600x1440 | 1320x600x1440 |
| Steam caliber(mm) | DN20 | DN20 | DN20 | DN20 | DN25 | DN25 | DN25 | DN25 | DN25 |
| Drain outlet caliber(mm) | DN25 | DN25 | DN25 | DN25 | DN25 | DN25 | DN25 | DN25 | DN25 |
| Water inlet caliber(mm) | DN15 | DN15 | DN15 | DN15 | DN15 | DN15 | DN15 | DN15 | DN15 |
| Weight(kg) | 190 | 190 | 230 | 230 | 260 | 260 | 270 | 270 | 300 |
Note: Customization of 304/316L material and 1.0~2.5MPa rated pressure is available; The parameter configuration has changed due to continuous product improvement, and the specific parameters are subject to the product leaving the factory.
