1. Unique internal structural design
Water volume less than 50L
Built in soda water separator to reduce steam moisture content
2. Intelligent electronic control system
Fully automatic computer welding LCD display
Real time monitoring of operational status
Working status of electric heating tube
Boiler water level status
State of high and low steam pressure
Pump operation status
Fault alarm status
3. Energy saving technology
On demand activation and group control
Boiler information energy-saving control system
4. High quality components
High quality electric heating tube: 316L stainless steel, capable of withstanding high temperatures up to 900 ℃
Domestic well-known electrical accessories
Copper pipe connecting pipeline, anti-corrosion and rust proof
5. Security protection system
Overtemperature alarm and interlock protection
Automatic exhaust and pressure relief due to excessive pressure
Water shortage protection to prevent dry burning
Leak detection protection to ensure smooth gas supply
Flameout protection to avoid danger
6. Energy saving and environmental protection characteristics
Efficient combustion technology reduces fuel consumption
Utilizing off peak electricity to reduce operating costs
7. Application of non-destructive testing technology
X-ray inspection of boiler liner welds
Hydraulic test to verify structural integrity
8. Scientific design and aesthetic appearance
Cabinet design with a reasonable internal structure
CNC cutting and folding process, exquisite workmanship
High temperature spray treatment, durable and beautiful
|
Series Product Model
|
DM 200-0.8
|
DM 216-0.8
|
DM 240-0.8
|
DM 288-0.8
|
DM 300-0.8
|
DM 360-0.8
|
DM 432-0.8
|
DM 576-0.8
|
DM 720-0.8
|
|
Boiler Product Model
|
2xLDR 0.17-0.8 |
2xLDR 0.17-0.8 |
2xLDR 0.17-0.8 |
2xLDR 0.2-0.8 |
2xLDR 0.17-0.8 |
2xLDR 0.17-0.8 |
2xLDR 0.2-0.8 |
2xLDR 0.2-0.8 |
2xLDR 0.2-0.8 |
|
Electric power(KW)
|
200
|
216
|
240
|
288
|
300
|
360
|
432
|
576
|
720 |
| Rated evaporation(Kg/h) | 286 | 300 | 344 | 400 | 430 | 516 | 600 | 800 | 1000 |
| Source voltage(V) | 380 | 380 | 380 | 380 | 380 | 380 | 380 | 380 | 380 |
| Rated pressure(MPa) | 0.8 | 0.8 | 0.8 | 0.8 | 0.8 | 0.8 | 0.8 | 0.8 | 0.8 |
| Steam temperature(℃) | 175 | 175 | 175 | 175 | 175 | 175 | 175 | 175 | 175 |
| Power wire(mm²) | 185 | 185 | 2x120 | 2x120 | 2x120 | 2x185 | 2x185 | 2x240 | 2x300 |
| Dimension(mm)L*W*H | 1405 | 1405 | 1405 | 1405 | 1935 | 1935 | 1935 | 2652 | 3250 |
| 1050 | 1050 | 1050 | 1050 | 1050 | 1050 | 1050 | 1100 | 1100 | |
| 1600 | 1600 | 1600 | 1600 | 1800 | 1800 | 1800 | 2000 | 2200 | |
| Steam caliber(mm) | DN40 | DN40 | DN40 | DN40 | DN40 | DN40 | DN40 | DN40 | DN40 |
| Drain outlet caliber(mm) | 2xDN25 | 2xDN25 | 2xDN25 | 2xDN25 | 3xDN25 | 3xDN25 | 3xDN25 | 4xDN25 | 5xDN25 |
| Water inlet caliber(mm) | DN25 | DN25 | DN25 | DN25 | DN25 | DN25 | DN25 | DN25 | DN25 |
| Weight(kg) | 600 | 650 | 650 | 800 | 850 | 900 | 950 | 1300 | 1600 |
Note: Customization of 304/316L material and 1.0~2.5MPa rated pressure is available; The parameter configuration has changed due to continuous product improvement, and the specific parameters are subject to the product leaving the factory.
