15kW 10KG Copper Metal Industrial Induction Furnaces Melting Heater Medium Frequency Type
1.Supply Scope
The induction melting furnace is comprised of the following parts: 1 set of
protective cap, 1 set of protective gloves, 1 set of metal melting furnace body,
2 pcs of flexible connection cable, 2 pcs of connection wires, 1 pc of single wire,
1pc of foot switch, and 1 set of mini induction melting furnace heating power source.
2.Technical Parameters of Induction Melting Furnace
| Working Power | 15KW |
| Input voltage range | 70V-550V |
| Output oscillation frequency | 1-20KHZ |
| Output current | 3-22A |
| Weight |
Main machine: 30kg; Control cabinet: 25kg |
| Dimension |
Furnace: 800*550*750mm (L*W*H); Power supply: 530*290*520mm (L*W*H); Control cabinet: 500*230*460mm (L*W*H)； |
| Capacity | 10KG copper |
| Cooling type | Water cooling |
| Cooling water requirement |
≥0.2Mpa ≥6L/min |
3.Main Features
3.1The main power devices of the induction melting furnace are all German Siemens brands,
and the main electronic components are imported products (Motorola (diode), NEC (triode),
ST (three terminal voltage regulator), FAIRCHILD, ON etc., which make them work stably
and have higher reliability and durability.
3.2 The induction metal melting furnace adopts IGBT power device and unique frequency
conversion technology to operate stably and provide higher reliability and durability. It has
the function of constant current and constant power control, which greatly optimizes the
metal heating process, realizes efficient and fast heating, and gives full play to the advantages
of the product. Under the same conditions, it has twice the power saving than the traditional
SCR medium frequency. With 100% load design, it can work continuously for 24 hours
and improve heating quality.
4. Products Supplied by Our Company
Our company supplies various induction furnaces, and the capacity of the furnace varies
from 1kg to 15ton based on different metals. We have induction melting furnace for copper,
zinc, steel, silver, gold, brass, and stainless steel. We have low frequency, medium frequency
and high frequency heating machine and metal melting furnaces. We have mini cabinet type
precious metal induction melting furnace,small capacity tilting type melting furnaces and
large capacity industrial induction metal melting furnaces (steel shell and aluminum shell type).
