160KW 100KG Cast Iron Industrial Induction Furnace Steel Melting Furnace Heater Medium Frequency Type
1. Features
The medium frequency induction steel melting furnace has alarm function and fault
detection function, such as fault state protection and display including overcurrent,
overvoltage and water shortage, etc. The furnace is user friendly since it is very easy
in operation. The medium frequency induction steel melting furnace has magnetic mixing
function which makes the melting process more unified.
2. Technical Parameters of Induction Melting Furnace
| Working Power | 160KW |
| Input voltage range | 70V-550V |
| Output oscillation frequency | 1-20KHZ |
| Output current | 35-290A |
| Weight |
Main machine: 80kg; Control cabinet: 70kg |
| Dimension |
Furnace: 1050*790*1200mm(L*W*H); Power supply: 750*500*960mm(L*W*H); Control cabinet: 550*400*510mm (L*W*H) |
| Capacity | 100KG cast iron |
| Cooling type | Water cooling |
| Cooling water requirement |
≥0.5Mpa ≥30L/min |
| Supply scope |
Heating power source, 1 set; Foot switch, 1 pc; Connection wire 2pcs; single wire 1 pc; Metal melting furnace body 1set; flexible connection cable 2pcs; User manual 1 copy; |
3. Main Features
3.1 The main power devices of the metal induction heater (also called as induction melting furnace)
are all German Siemens brands, and the main electronic components are imported products
(Motorola (diode), NEC (triode),ST (three terminal voltage regulator), FAIRCHILD, ON etc.,
which make them work stably and have higher reliability and durability.
3.2 The metal induction heater melting furnace adopts IGBT power device and unique frequency conversion
technology to operate stably and provide higher reliability and durability. It has the function of constant current
and constant power control, which greatly optimizes the metal heating process, realizes efficient and fast heating,
and gives full play to the advantages of the product. Under the same conditions, it has twice the power saving
than the traditional SCR medium frequency. With 100% load design, it can work continuously for 24 hours
and improve heating quality.
3.3 Our company can provide a wide range of induction melting furnaces. The capacity ranges from 1kg to
20Ton and for metals such as zinc, copper, steel, iron, aluminum, lead, etc.
3.4 The steel metal induction melting furnace has the advantages of wide application, easy operation, small floor
area required, environmetal friendliness, fast heating speed, low power consumption, high efficiency, and good effect.
