| Name | Electric Resistance Car Bottom Furnace |
|---|---|
| Working size | 1200×600×450mm(L×W×H) |
| Working temperature | 950℃ |
| Control zone | 1 Zone |
| Parts to be treated | Steel Structure Parts, Cast Steel Parts, Shaft Bar Parts, Tool Steel Products |
| Name | Car Bottom Furnace |
|---|---|
| Process | Fast Quenching |
| Working Size | 3000*1350*950mm Or Customized |
| Working Temperature | 950 Degree |
| Rated Power | 320KW |
| Name | Heat Treatment Furnace Bogie Hearth Furnace |
|---|---|
| Fuel | Natural Gas |
| Rated Temperature | 1200 Degree |
| Burner | 8pcs, AGS 140HB, 450kw/h |
| Bogie Max Loading Capacity | ≤60000kg |
| Name | Aluminum Heat Treatment Furnace |
|---|---|
| Parts To Be Treated | Aluminum Plates And Circles |
| Type | 2-trolley Type |
| Working Size | 2700×1600×1100mm |
| Temperature | 600℃ |
| Name | Bogie Hearth Heat Treatment Furnace |
|---|---|
| Fuel | Natural Gas |
| Working Size | 2000*1000*1000mm |
| Max Temperature | 1300 Degree |
| Furnace Lining | Heat Resistant All Fiber Structure |
| Name | Car Type Heat Treatment Furnace |
|---|---|
| Process | Stress Relief |
| Working Size | 3000×1600×1400mm |
| Working Temperature | 950 Degree |
| Rated Power | 250KW |
| Name | Aluminum Alloy Fast Quenching Furnace |
|---|---|
| Working size | 4500×2500×2500mm(L×W×H) |
| Working temperature | 1000℃ |
| Control zone | 4 Zones, Independent Temperature Control |
| Parts to be treated | Hheat Treatment Processing Such As Clay Pot Heating Molding |
| Name | Heat Treatment Furnace Trolley Type Furnace |
|---|---|
| Fuel | Natural Gas |
| Working Size | 2000*1000*1000mm |
| Max Temperature | 1300 Degree |
| Heating Zone | 1 Zone |
| Name | Car Bottom Heat Treatment Furnace |
|---|---|
| Fuel | Natural Gas |
| Working Size | 1500*2000*3000mm |
| Rated Temperature | 1200 Degree |
| Heating Zone | 2 Zone |
| Name | Fast Quenching Heat Treatment Furnace |
|---|---|
| Working size | 1500×800×800mm(L×W×H) |
| Working temperature | 1400℃ |
| Control zone | 2 Zones (one For Furnace Body, One For Bogie) |
| Parts to be treated | Steel Structure Parts, Cast Steel Parts, Shaft Bar Parts, Tool Steel Products |
