Accurate Dosing and Temperature Control for Optimal Results in Industrial Aluminum Melting Furnace
1.Operation principle of Aluminum alloy dosing & holding furnace
WDL pneumatic dosing furnace is designed to take metal below the surface of the metal liquid
in the bath, which can avoid completely the oxidization slug and tremendously imp rove the
quality of the alloy liquid.WDL pneumatic dosing furnace is designed to feed directly and
automatically to the diecasting machine or gravity mold free of any contamination.In order
to feed the alloy liquid, overpressure is formed inside the furnace chamber .The level of alloy
liquid inside the rising tube is raised first until the alloy liquid is about to overflow. When the
diecasting machine request the alloy liquid, the pressure inside the furnace chamber will be
increased further in order for the alloy liquid to flow out. The pressure will be decreased to end
the dosing once preset amount being reached.After dosing completed, the liquid level is raised
back to the feeding level for the next dosing.
| 2. Features | |
| Dosing accuracy | ＜土1.5% |
| holding temperature | ＜土1.5℃ |
| Dosing time | 3- 30s |
| loss ratio | <0.06% |
| electric consumption | 1/3 of normal ladling system |
| high quality | The quality of aluminum liquid is guaranteed as the metal is taken from the bottom |
| Closed Chamber | Ensure to keep the oxidation film complete,reduce oxidation slug, as well as lessen the slug clearing time. |
| Life span | normal use 10 years above(furnace lining) electrical parts 10 years above. |
| dosing range | 0.5KG- 100KG from 0.5kg to 100kg |
| on-line degasing | for high end casting parts |
| synchronization | Communication adopts network and cable connection,Both optional |
| data storage | Molding process data storing function, One-key saving function for molding change and accessing function |
| structure design | easy installation and commissioning |
| spare parts | compatible parts, ensure minimum stock level for customers. |
| high efficiency | Comparing with other feeding method, holding furnace has higher efficiency, no waiting time and higher production efficiency |
| Safety assurance | measures applied in electrical protection, mechanical protection,interlock between electrics and mechanism.as well as mis-operation-proof |
| Thermostatic control | air-con applied in main control panel |
3. Pneumatic metering furnace
WDL Pneumatic Holding Furnace is the holding and dosing system for the clear
and closed liquid aluminum,and is applied to aluminum.WDL Pneumatic Holding
Furnace, ranging from 500KG to 4100KG, is applied to all kinds of different types
of diecasting machine and the dosing, ranging from 0.5KG to 100KG, can meet
almost all types of casting parts. The furnace adopts the most advanced control
system of Siemens and is able to improve product quantity and quality due to the
outstanding features of safe reliability, easy installation, simple operation and
efficient dosing speed.
4. Technical Requirements
