1. Highlights
1.1 The electric aluminum holding furnace adopts the high strength
steel plate with a great strength.
1.2 The resistance heating method has a big heat radiation range,
and a low metal burning loss. The
heating element is equipped with the protection casing pipe
of good conductivity.
1.3 Direct measurement of aluminum liquid temperature. The
electric aluminum holding furnace has
double temperature control and measurement, which enables a
control accuracy of ±5℃ of the aluminum liquid.
1.4 Lining is made of imported high-quality material, and casted
as a whole. 1.5 The lining has a life of 5
years based on normal use.
1.6 The electric aluminum holding furnace is equipped with a
safety valve to prevent over-pressure.
1.7 The electric aluminum holding furnace can move horizontally
and up-down based on the customers requirement.
2. Technical parameters
| Model | Holding Capacity (kg) | Rated Power (kw) | Max Pressure (Mpa) |
Overall Dimension (mm) L* W*H |
| WDL-BDD-300 | 300 | 21 | 0.09 | 1900*1600*1200 |
| WDL-BDD-500 | 500 | 27 | 0.09 | 2100*1800*1300 |
| WDL-BDD-800 | 800 | 32 | 0.09 | 2300*1900*1400 |
| WDL-BDD-1000 | 1000 | 36 | 0.09 | 2400*2000*1450 |
