Wondery Plasma Ion Nitriding Furnace Heat Treatment Furnace for stainless steel parts
1.Summary
Our company is specialized in ion nitriding process research and equipment production. We have accumulated rich experience in the design and production of industrial ion nitriding furnace. The main products are ion nitriding furnaces, pulse ion nitriding furnace and ion nitriding furnaces with auxiliary heating. Our goal is to improve product quality and create greater benefits for users.
2.What is an ion nitriding process?
Ion nitriding is a chemical heat treatment process that can significantly improve the surface hardness, wear resistance, fatigue resistance and corrosion resistance of steel parts.
Place the parts to be treated in the vacuum ion nitriding heat treatment furnace, and fill the furnace with thin nitrogen-containing gas under vacuum conditions. The parts are connected to the cathode of the ion power supply, the furnace body is connected to the anode, and the anode and cathode are connected to hundreds of volts DC voltage. Due to the action of electric field, the rarefied gas in the furnace is ionized, nitrogen ions impact the cathode (part) directionally, and the surface of the part generates glow discharge and is heated. Under a certain atmosphere and temperature, the surface of the parts recombines and absorbs nitrogen atoms, forming a high concentration nitrogen-containing layer and diffusing to the center. After a period of time, the nitriding layer required by the process requirements is obtained.
Ion nitriding process has been widely used in power, machine tools, petrochemical machinery, light textile machinery, tooling and other industries because of its advantages of energy saving, gas saving, high efficiency and good quality.
3.Technical Parameters of Ion Nitriding Furnace
3.1 main parameters of DC ion power supply
DC output voltage: 0-1000v adjustable
Large output current of DC power supply:
| MODEL | WDL30A | WDL50A | WDL75A | WDL100A | WDL150A | WDL300A |
| CURRENT | 30A | 50A | 75A | 100A | 150A | 300A |
Arc extinguishing mode: LC oscillation arc extinguishing and cut-off arc extinguishing
3.2 main parameters of pulse power supply
Large output current of pulse power supply:
| MODEL | WDLC30A | WDLC50A | WDLC75A | WDLC100A | WDLC150A | WDLC300A |
| AVERAGE CURRENT | 30A | 50A | 75A | 100A | 150A | 300A |
| PEAK CURRENT | 60A | 100A | 150A | 200A | 300A | 400A |
