10KG Tilting Type Induction Industrial Metal Steel Melting Furnace 35KW Medium Frequency Type
1.Main Features
1.1The induction industrial metal steel melting furnace adopts IGBT power device
and unique frequency conversion technology to operate stably and provide higher
reliability and durability. Under the same conditions, it has twice the power saving
than the traditional SCR medium frequency.
1.2The industrial metal steel melting furnace has alarm function and fault detection
function, such as fault state protection and display including overcurrent, overvoltage
and water shortage, etc.
1.3The tilting type induction steel melting furnace has a small and compact structure.
It is very easy in installation and operation.
1.4 The industrial metal steel melting furnace has a fast melting speed and saves
energy consumption.
1.5 The main power devices of the induction industrial metal steel melting furnace
are all German Siemens brands, and the main electronic components are imported
products (Motorola (diode), NEC (triode), ST (three terminal voltage regulator), FAIRCHILD, ON etc..
2. Technical Parameters of Industrial Metal Steel Melting Furnace
| Furnace name | Industrial metal melting furnace |
| Furnace type | Medium frequency induction |
| Input voltage range | 70V-550V |
| Output oscillation frequency | 1-20KHZ |
| Cooling type | Water cooling |
| Water pump | 1 set supplied |
| Material to be melted | Steel, iron, stainless steel |
| Capacity of industrial metal melting furnace | 10kg steel |
| Overall dimension (L,W,H, mm) |
Furnace body:830*560*920mm power cabinet:630*340*540mm capacitor cabinet:500*230*460mm |
| Working power supply | Three phase 380V 50 / 60Hz |
| Operating voltage range | 340-480V |
| Output current | 1-70A |
| Cooling water volume | 0.08-0.16Mpa 9L/min |
| Water temperature protection point | 40℃ |
Notes: We also have medium and large size induction metal melting furnace. The max capacity of
the furnace reaches 20Ton or more. We provide customzied service.
3. Company Supply Scope
Our company is a professional supplier of steel melting furnaces. We have medium frequency
compact structure steel melting furnace, steel shell steel melting furnace, and aluminum shell
steel melting furnaces. Our steel melting furnace products can meet the production needs in the
process of melting stainless steel, steel, and iron material.
