1.1 Ultra-high heat utilization efficiency, and low power consumption.
The aluminum holdig furnace saves power consumpstion by more than
40% compared wih the traditional radiation type holding furnace.
1.2 There is no aluminum liquid burning loss or slag hanging phenomenon.
1.3 The aluminum holding furnace adopts high quality refractory material
with a long lining service life (up to 5 years under normal use condition)
1.4 Adopt Japanese imported protective tube which has a long service life,
safe and stable.
1.5 The Control Panel has multiple safety functions such as aluminum
liquid over-temperature alarm, atmosphere over-temperature alarm, heater
circuit breakage alarm, etc.
1.6 The immersion type heating element is imported from Germany.
2. Technical Parameters
| Model | Holding Capacity (kg) | Rated Power (kw) | Overall Dimension (mm) | Ladling Size (mm) |
| WDL-BJD-500 | 500 | 12 | 1800*1400*1400 | 400*400 |
| WDL-BJD-700 | 700 | 14 | 1980*1600*1400 | 450*450 |
| WDL-BJD-900 | 900 | 14 | 2120*1600*1500 | 500*500 |
| WDL-BJD-1200 | 1200 | 16 | 2300*1800*1550 | 500*500 |
| WDL-BJD-1500 | 1500 | 21 | 2600*1800*1600 | 500*500 |
| WDL-BJD-2000 | 2000 | 30 | 2900*2100*1650 | 600*550 |
| WDL-BJD-2500 | 2500 | 36 | 3200*2200*1700 | 700*700 |
3. Product Scope
Our company has a wide range of aluminum melting furnaces and aluminum
holding furnaces for die casting operation. We have electric type, gas type or oil
type aluminum holding furnaces. We also have induction type, electric resistance type,
gas type or oil type aluminum melting furnace.
Continuous Aluminum Melting Furnace for Die Casting Operation:
