1. Features of Crucible Melting Furnace
1.1 The gas fired aluminum melting furnace lining is composed of the
casting material and the ceramic fiber
module material, which has the characteristics of good heat preservation effect,
small heat storage and fast
heating rate. The wall temperature rise is ≤ 40℃.
1.2The gas fired aluminum melting furnace adopts separation type burning
system with PID control, which
significantly reduces energy consumption. The temperature control accuracy
reaches ±5℃.
1.3The gas fired aluminum melting furnace is equipped with one thermal
couple protected by the silicon
nitride outer pipe, and this thermal couple could directly measure the
aluminum liquid.
1.4The gas fired aluminum melting furnace adopts European brand
graphite crucible, which has a good
thermal conductivity, a long life, and no iron hyperplasia.
1.5The gas fired aluminum melting furnace is equipped with liquid leak
alarm, over-temperature alarm
and other functions to ensure the safety of equipment and operation.
1.6 The metal liquid is automatically poured out, easy, safe and reliable.
2. Technical parameters
| Model | Crucible Capacity (kg) | Melting Capacity (Melting Capacitykg/h) |
Overall Dimension (mm) L * W* H |
| WDL-RGQ-350 | 350 | 150 | 1500*1600*1750 |
| WDL-RGQ-500 | 500 | 200 | 1670*1700*1800 |
| WDL-RGQ-800 | 800 | 300 | 1800*1800*1900 |
| WDL-RGQ-1000 | 1000 | 400 | 1800*2100*2400 |
3. Company Introduction
Our company is a professional supplier of induction melting furnace (steel shell
and aluminum shell type), gas type cruicble
melting furnace, gas type tower type aluminum melting furnace, tilting type
induction melting furnace, etc.
