Pit Well Type Spheroidizing Bright Annealing Heat Treatment Furnace
1. Application of Heat Treatment Furnace
The heat treatment furnace is used for spheroidizing treatment of wires, aluminum alloy
wires, copper wires or other nodule wires.
2. Purpose of Annealing
The purpose of annealing is to heat the steel whose structure deviates from the equilibrium
state to an appropriate temperature, hold it for a certain time, and then cool it slowly
(cooling with the furnace) to obtain a heat treatment process close to the equilibrium structure.
There are many kinds of annealing processes for steel, which can be divided into two categories
according to the heating temperature: one is annealing above the critical temperature (AC1 or AC3),
also known as phase transformation recrystallization annealing, including complete annealing,
incomplete annealing, spheroidizing annealing and diffusion annealing (homogenization annealing).
The other is annealing below the critical temperature, including recrystallization annealing and stress
relief annealing. According to the cooling method, annealing can be divided into isothermal annealing
and continuous cooling annealing.
3. Main Specifications and Parameters
| Model | Rated power (kw) |
Rated temperature (degree celcius) |
Effective size (mm) |
Loading capacity(kg) |
| RJ-1 | 1800 | 800 | 2000*2000 | 6000 |
| RJ-2 | 300 | 800 | 2200*2000 | 8000 |
| RJ-3 | 400 | 800 | 3200*2000 | 16000 |
| RJ-4 | 480 | 800 | 3200*3000 | 20000 |
| RJ-5 | 580 | 800 | 3500*3200 | 30000 |
4. Our Product Range
Our company supplies a wide range of heat treatment furnaces such as car bottom heat treatment furnace,
pit type heat treatment furnace,salt bath heat treatment furnace, pit type carburizing furnace, mesh belt heat
treatment furnace, box type heat treatment type, etc.
