Roller Hearth Resitance Heat Treatment Furnace for Quenching Tempering Treatment
1. Introduction
The roller hearth heat treatment furnace is automatic production line which is the latest quenching
and tempering production line developed by our company, which is the first in China.We have also
obtained the invention patent and utility model patent for the heat treatment furnace.
2. Application
The roller hearth heat treatment furnace is mainly used in the heat treatment and quenching
and tempering process of carbon structure steel,alloy steel bars and pipes. It is an ideal production
line for heat treatment and quenching
and tempering
of special steel, screw and pipe manufacturers.
3. Main Specifications and Parameters
| Model | Rated power (kw) | Workpieces specification |
Effective working size (mm) |
Temperature zone |
Production Capacity (kg/h) |
| GD-1 | 300 | DIA12-50*4000 | 800*8000*100 | 5 | 500-700 |
| GD-2 | 400 | DIA12-50*6000 | 800*10000*100 | 6 | 700-1000 |
| GD-3 | 500 | DIA12-50*8000 | 800*12000*100 | 7 | 900-1300 |
| GD-4 | 700 | DIA12-50*12000 | 800*16000*100 | 8 | 1250-1600 |
4. Product Range
We are a full range heat treatment supplier for heat treatment furnaces. We have mesh belt furnace,
bogie hearth furnace,pit type furnace,box type heat treatment furnace, and rotary type heat treatment furnace.
The energy medium can be gas or electricity. We provide customized service for our customer.
